SCS Automaberg S.r.l.

HCR Head Corner Rounding

Table corner rounding unit

Table corner rounding unit with one punch only. Sturdily built, easy adjusting. Just insert the cover, the punching tool comes down and allows the perfect rounding of the corner.

Ideal for small production.

Advantages

  • Simplicity of operation
  • Reduced space
Operation

Covers are insert manually and 2 sensors will allow the corner rounding starting. The heating resistance in the punch will soften the glue before the corner will be rounded, raising a perfect result. The temperature is adjustable and can be excluded. A pressing time potentiometer allows to establish the pressing time.



Technical data

Open cover sizemin. 80 x 50 mm
Supply voltage230 V / 1 ph / 50 Hz
Installed Power0,3 kW
Compressed Air Requirement0.3 ltr/cycle at 6 bar
Weight30 kg
Dimensions (L x W x H)400 x 650 x 375 mm

Technical data subject to change without notice

dati_tecnici_cornermaster
Italian Custom Design
